Determination of Multiple Components in Maltooligosaccharide by HILIC-ELSD-ESI-Q-TOF/MS
-
摘要: 建立亲水色谱-蒸发光散射检测器-电喷雾-四级杆-飞行时间串联质谱（HILIC-ELSD-ESI-Q-TOF/MS）技术用于工业低聚麦芽糖中化学成分的快速鉴别及其含量测定的方法。以低聚麦芽糖为研究对象，采用HILIC法对低聚麦芽糖进行快速分离，ESI-Q-TOF/MS法对多种化合物进行鉴别，依据其精确分子质量、MS/MS裂解特征、色谱保留行为等信息，结合对照品信息和文献报道等对其进行验证，并采用HILIC-ELSD对已知成分进行定量测定。结果表明，采用亲水色谱法进行测定，低聚麦芽糖中各成分分离度较好；应用ESI-Q-TOF/MS鉴定出工业低聚麦芽糖中的10种成分；其中7种化合物（葡萄糖、麦芽糖、麦芽三糖、麦芽四糖、麦芽五糖、麦芽六糖、麦芽七糖）回归方程的相关系数均优于0.9990，表明线性关系良好；平均回收率在95.66%~99.00%范围内，相对标准偏差在1.11%~4.93%范围内；检出限在0.004~0.070 μg/mL之间，定量限在0.013~0.233 μg/mL之间。对7种成分定量测定表明，麦芽七糖的含量（14.31%±0.13%）最高，其次为麦芽三糖（9.34%±0.14%），麦芽六糖（7.49%±0.09%）。麦芽糖、麦芽三糖、麦芽四糖、麦芽五糖、麦芽六糖和麦芽七糖的总含量则达到了43.39%±0.35%。该方法分离度好、灵敏度高，可以对多种不同聚合度低聚麦芽糖成分进行定性和定量分析，为低聚麦芽糖工业化生产及应用的质量控制提供了一种分析方法支持。
-
关键词:
- 超高效液相色谱 /
- 亲水色谱 /
- 电喷雾-四级杆-飞行时间质谱 /
- 低聚麦芽糖
Abstract: A rapid identification and determination method of chemical components in industrial maltooligosaccharide was established by HILIC-ELSD-ESI-Q-TOF/MS technology. Taking maltooligosaccharide as the research object, the rapid separation of maltooligosaccharide was carried out by HILIC method, and a variety of compounds were identified by ESI-Q-TOF/MS method. Based on the accurate molecular weight, MS/MS fragmentation characteristics, chromatographic retention behavior and other information, combined with reference material information and literature reports, the known components were quantitatively determined by HILIC-ELSD. The results showed that the separation of the components in maltooligosaccharide was good by hydrophilic chromatography. Ten components in maltooligosaccharides were identified by ESI-Q-TOF/MS, the correlation coefficients of the regression equations of the seven compounds(glucose, maltose, maltotriose, malttetrasaccharide, maltpentasaccharide, malthexose, maltohexaose) were all better than 0.9990, indicating a good linear relationship. The average recoveries were in the range from 95.66% to 99.00% with relative standards deviation between 1.11% and 4.93%. The limits of detection ranged from 0.004 to 0.070 μg/mL and limit of quantitation between of 0.013~0.233 μg/mL. The quantitative determination of seven components showed that the content of maltose was the highest(14.31%±0.13%), followed by maltotrisaccharide(9.34%±0.14%) and maltohexose(7.49%±0.09%). The total contents of maltose, maltotrisaccharide, maltotrisaccharide, maltopentose, maltohexose and maltoheptoglycose reached 43.39%±0.35%. The method had good resolution and high sensitivity, and could be used for qualitative and quantitative analysis of maltose with different degree of polymerization. It provides an analytical method support for the industrial production and application of maltooligosaccharides.-
Keywords:
- UPLC /
- HILIC /
- ESI-Q-TOF/MS /
- maltooligosaccharide
-
[1] 杨洋,王卫国.功能性低聚糖在饲料工业中的应用[J].广东饲料,2002,11(3):29-31. [2] 杨海军,李发财,袁伟涛.低聚麦芽糖在固体饮料中的应用[J].食品安全导刊,2011(12):50. [3] 马莺,王明丽.低聚糖的生产及应用[J].中国食品工业,2001(3):30-31. [4] 杨彬君,易骏,龚业滔,等.GC-MS分析牛樟芝多糖的单糖组成及其抗氧化活性[J].食品工业科技,2019,40(12):85-89. [5] 何连军,干雅平,吕伟德,等.高效阴离子交换色谱-脉冲安培检测法测定多花黄精多糖的单糖组成[J].中草药,2017,48(8):1671-1676. [6] Yan J,Shi S S,Wang H W,et al. Neutral monosaccharide composition analysis of plant-derived oligo-and polysaccharides by high performance liquid chromatography[J].Carbohydrate Polymers,2016,136:1273-1280.
[7] Liu J,Zhou J,Zhang Q Q,et al. Monosaccharide analysis and fingerprinting identification of polysaccharides from Poria cocos and Polyporus umbellatus by HPLC combined with chemometrics methods[J].Chinese Herbal Medicines,2019,11(4):406-411.
[8] 赵宏,柴桂芳,王秋红,等.一种车前子多糖的分离纯化及单糖组成分析[J].中国实验方剂学杂志,2014,20(19):97-100. [9] Zhao P,Li X,Wang Y,et al. Characterisation and saccharide mapping of polysaccharides from four common Polygonatum spp[J].Carbohydrate Polymers,2020,233:115836.
[9] Zhao P,Li X,Wang Y,et al. Characterisation and saccharide mapping of polysaccharides from four common Polygonatum spp[J].Carbohydrate Polymers,2020,233:115836.
[10] 中华人民共和国国家质量监督检验检疫总局. GB/T 20883-2017麦芽糖[S]. 北京:中国标准出版社,2017. [10] 中华人民共和国国家质量监督检验检疫总局. GB/T 20883-2017麦芽糖[S]. 北京:中国标准出版社,2017. [11] 吴红京,唐根源,李志达,等. 高效液相色谱测定麦芽低聚糖的组分[J]. 色谱,1994,12(4):289-290. [11] 吴红京,唐根源,李志达,等. 高效液相色谱测定麦芽低聚糖的组分[J]. 色谱,1994,12(4):289-290. [12] 林家永.异麦芽低聚糖含量测定方法的研究[J].食品工业科技,2009,30(6):351-353 ,387.
[12] 林家永.异麦芽低聚糖含量测定方法的研究[J].食品工业科技,2009,30(6):351-353 ,387.
[13] 阳曦,刘玮.亲水作用色谱-串联质谱法测定婴幼儿乳粉中的牛磺酸[J].食品工业科技,2019,40(8):225-228 ,259.
[13] 阳曦,刘玮.亲水作用色谱-串联质谱法测定婴幼儿乳粉中的牛磺酸[J].食品工业科技,2019,40(8):225-228 ,259.
[14] Cao C Y,Wang L L,Wang L L,et al. A strategy to identify mixed polysaccharides through analyzing the monosaccharide composition of disaccharides released by graded acid hydrolysis[J].Carbohydrate Polymers,2019,223:115046.
[14] Cao C Y,Wang L L,Wang L L,et al. A strategy to identify mixed polysaccharides through analyzing the monosaccharide composition of disaccharides released by graded acid hydrolysis[J].Carbohydrate Polymers,2019,223:115046.
[15] 梁图,傅青,辛华夏,等.基于部分酸水解-亲水作用色谱-质谱的黄芪多糖结构表征[J].色谱,2014,32(12):1306-1312. [15] 梁图,傅青,辛华夏,等.基于部分酸水解-亲水作用色谱-质谱的黄芪多糖结构表征[J].色谱,2014,32(12):1306-1312. [16] Gao Y Y,Jiang Y,Chen G C,et al. A sensitive and rapid UPLC-MS/MS method for determination of monosaccharides and anti-allergic effect of the polysaccharides extracted from saposhnikoviae Radix[J].Molecules,2018,23(8):1924.
[16] Gao Y Y,Jiang Y,Chen G C,et al. A sensitive and rapid UPLC-MS/MS method for determination of monosaccharides and anti-allergic effect of the polysaccharides extracted from saposhnikoviae Radix[J].Molecules,2018,23(8):1924.
[17] Allison C L,Lutzke A,Reynolds M M.Identification of low molecular weight degradation products from chitin and chitosan by electrospray ionization time-of-flight mass spectrometry[J]. Carbohydrate Research,2020,493:108046.
[17] Allison C L,Lutzke A,Reynolds M M.Identification of low molecular weight degradation products from chitin and chitosan by electrospray ionization time-of-flight mass spectrometry[J]. Carbohydrate Research,2020,493:108046.
[18] Li C T,Seeram N P.Ultra-fast liquid chromatography coupled with electrospray ionization time-of-flight mass spectrometry for the rapid phenolic profiling of red maple(Acer rubrum)leaves[J].Journal of Separation Science,2018,41(11):2331-2346.
[18] Li C T,Seeram N P.Ultra-fast liquid chromatography coupled with electrospray ionization time-of-flight mass spectrometry for the rapid phenolic profiling of red maple(Acer rubrum)leaves[J].Journal of Separation Science,2018,41(11):2331-2346.
[19] Xi X J,Xiao S Z,Tang F,et al. Monosaccharide analysis of dendrobium moniliforme polysaccharides by High Performance liquid chromatography/electrospray ionization mass spectrometry[J]. American Journal of Agriculture and Forestry,2016,4(6).
[19] Xi X J,Xiao S Z,Tang F,et al. Monosaccharide analysis of dendrobium moniliforme polysaccharides by High Performance liquid chromatography/electrospray ionization mass spectrometry[J]. American Journal of Agriculture and Forestry,2016,4(6).
[20] Liang Y T,Zhou J H,Nan T G,et al. Analysis of monosaccharide composition of twelve polysaccharides by pre-column derivatization procedure UPLC-MS/MS[J].Zhongguo Zhong Yao Za Zhi,2018,43(22):4469-4473.97-100.
[20] Liang Y T,Zhou J H,Nan T G,et al. Analysis of monosaccharide composition of twelve polysaccharides by pre-column derivatization procedure UPLC-MS/MS[J].Zhongguo Zhong Yao Za Zhi,2018,43(22):4469-4473.
